Aibecy LCD Display Adjustable Direct Current Stabilized Voltage Power Supplys Base Plate Constant Voltage and Constant Current 20A 1200W Step-down Module Base Plate

Two types optional you can choose -6020L and -6020L base plate depending on your demands. -6020L: Includes a voltage regulator a base plate and 2 cables. The direct current voltage regulator is constant voltage and current design with the output voltage of 0.0-60.00V output current of 0.0-20.00A and output power of 1200W. Full-view special power supplys LCD large screen display complete data display simple operation can provide stable working performance. -6020L base plate: Output voltage can be set with the fixed voltage output of 591224364860V. Low-cost communication power supplys through a TTL to 485 module or WIFI module it can realize the remotely controls of multiple machines a separate base board can realize communication control low-cost solution. Features: Voltage Stabilizer: direct current voltage regulator which is constant voltage and current design with the output voltage of 0.0-60.00V output current of 0.0-20.00A and output power of 1200W. Full-view special power supplys LCD large screen display complete data display simple operation can provide stable working performance. In the operation interface short press the encoder button the power (W) capacity (Ah) energy (Wh) time (h) will be displayed in turn in the downstream; short press the SW button switch into the input and output voltage display; long press the encoder button for 2 seconds to lock the set voltage and current to prevents misoperation. 10 groups of storage function there are 10 groups of data from CD0 to CD9 (CD8=12 V; =24 V is not adjustable) the data is saved to CD0 by default. Support serial communication standard MODBUS protocol. Multiple protections voltage under voltage protecting over voltage protecting over current protecting over power protecting over capacity protecting timeout protecting over protecting external protecting. Multi-parameter value setting support setting input voltage undervoltage protecting value overvoltage protecting value overcurrent protecting value overpower protecting value maximum capacity maximum energy running time power-on status and running interface rotary encoder default setting parameters ( or ). Base Plate: Solid material input adopts a common-mode inductor significantly reduce the impact of the input power supplys wavenumber to achieve low wavenumber output. Intelligent control design fan with large area heat sink with superior heat dissipation effect. Output voltage can be set by dip switch with the fixed voltage output of 591224364860V. And the base plate can be used independently the output current of 0-20A the back of the base plate with true value table. Low-cost communication power supplys through a TTL to 485 module or WIFI module it can realize the remotely controls of multiple machines a separate base board can realize communication control low-cost solution. Specifications: Name: Direct Current Voltage Stabilizer Material: plastics+rinted circuit board Type: -6020L -6020L base plate (optional) Input voltage: 6.0-70V Output voltage: 0.0-60V Output current: 0-20.00A Output ripple typical value: 100mv VPP Output power: 0-1200W Maximum output voltage: (input voltage ÷ 1.1)-2 Input voltage measurement resolution: 0.01V Output voltage setting measurement resolution: 0.01V Current setting: 0.01A Input voltage measurement resolution measurement accuracy: ±1% + 5 words Output voltage setting: ±0.4% + 1 word Output current setting and measurement accuracy and measurement accuracy: ±0.5% + 3 words Cooling fan on: current>2A power>50W >50℃ C
