AYS-S21 HD/3D 2 x 1 SDI Switch
Description
The SDI Switch allows you to determine which of two connected SDI video sources will be displayed on the SDI monitor. This switch supports bit rates up to 2.970 Gbps and supports SD-SDI, HD-SDI, and 3G-SDI video signals.
Features
Support for multiple standard and high definition video resolutions up to 3G 1080p @ 50, 60 Hz.
Data rates up to 2.97 Gbps.
Automatically switches between SD, HD and 3 Gb/s SDI standards.
Support 3Gbps data rate for tmds clock up to 300MHz.
Support 8/10/12bit deep color.
Specifications
Input Connector2x SDI BNC Male
Output Connector1x SDI BNC Male
Supported Cable Lengthup to 180m(input+output)
SMPTE425M Level A&B, 424M, 292M, 259M-C
Rate270Mb/s（SD), 1.485Gb/s(HD), 2.97Gb/s(3G)
Power2W
Input VoltageDC 5V-12V
Product Size125x66.5x22 (mm)
Package Contents1 x SDI Switch
Features
Support for multiple standard and high definition video resolutions up to 3G 1080p @ 50, 60 Hz.
Data rates up to 2.97 Gbps.
Automatically switches between SD, HD and 3 Gb/s SDI standards.
Support 3Gbps data rate for tmds clock up to 300MHz.
Support 8/10/12bit deep color.
Specifications
Input Connector2x SDI BNC Male
Output Connector1x SDI BNC Male
Supported Cable Lengthup to 180m(input+output)
SMPTE425M Level A&B, 424M, 292M, 259M-C
Rate270Mb/s（SD), 1.485Gb/s(HD), 2.97Gb/s(3G)
Power2W
Input VoltageDC 5V-12V
Product Size125x66.5x22 (mm)
Package Contents1 x SDI Switch
