AMDIB16 DC 12V 24V 16 Channels NPN PNP Digital Input Module RS485 3KV Isolated Communication MODBUS RTU PLC Expansion Bo
sku: 1977542
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$27.99
Shipping from: China
Description
Description 1 16ch optoelectronic 3kV isolation digital input channel NPN PNP optional 2 RS485 MODBUS RTU standard communication protocol3 Netted with configuration software PLC or industry touch panel4 Communication circuit designed for thunder protection and interference immunity5 Used for signal collection and control in industrial fieldSpecifications 1 Working voltage DC 7 25V 9V 12V 24V 2 Working current 8 50MA3 16 optically isolated input ports NPN PNP optional 4 RS485 communication isolation protection 3000VDC DI digital input port isolation protection 3000VDC5 Standard MODBUS RTU command function code 06 16 Write 02 03 Read 6 Baud rates 1200 2400 4800 9600 default 19200 38400 57600 1152007 Parity bits None default Even Odd8 Installation method Standard DIN rail installation9 Dimensions 125 70 30mm10 Weight 114gInterface Definition VCC Power input GND Power input DI1 Digital input channel 1DI2 Digital input channel 2DI3 Digital input channel 3DI4 Digital input channel 4DI5 Digital input channel 5DI6 Digital input channel 6DI7 Digital input channel 7DI8 Digital input channel 8DI9 Digital input channel 9DI10 Digital input channel 10DI11 Digital input channel 11DI12 Digital input channel 12DI13 Digital input channel 13DI14 Digital input channel 14DI15 Digital input channel 15DI16 Digital input channel 16A RS485 signal A B RS485 signal B Application 1 PLC Output expansion board2 Smart Home Home A
