AI-Thinker TB-02 Development Board bluetooth 5.0 Transparent Transmission Module BLE Mesh Controller 6 PWM Output

Instruction The TB 02 intelligent lighting module is a Bluetooth module based on the TLSR8250F512 chip and compatible with BT 5 0 low power Tmall Genie Mesh This module supports the Bluetooth module directly controlled by Tmall Genie and has a Bluetooth mesh networking function Peer to peer network communication using Bluetooth broadcast for communication can ensure timely response in the case of multiple devices It is mainly used in intelligent light control which can meet the requirements of low power consumption low latency and short range wireless data communication   Features Can be directly controlled by Tmall Elf without a gateway1 6mm pitch pin vertical solder DIP18 or SMD 13 package6 PWM outputsWith on board antenna no need to design antennaBrightness duty cycle adjustment range 5 100 Factory default 50 duty cycle for cool and warm colorsPWM output power 1KHzWith night light functionWith wall switch to switch color temperature function Model NameTB 02Size18 0 18 0 2 8 ±2 mmPackageDIP 18 or SMD 13Wireless StandardBluetooth V5 0Frequency Range2400 2483 5MHzOutput Power10dBmSensitivity 93dBmInterfaceGPIO PWM SPI ADCWork Temperature 20°C 70 °CStore Temperature 40°C 125°C 90 RHVoltage RangeVoltage 2 7V 3 6V Current 50mAPowerDeep Sleep Mode 0 8uASleep Mode 1 8uATX 12 62mATransmission Distance80m 150m  Documents   Manual Click here to open TB 02 hardware package Click here to open  Package includes   1 x TB 02 intelligent lighting module
