ADS1256IDB Analog to Digital Conversion Module 24 Bit ADC Data Acquisition Module Single Ended Differential Input

More document click to download: ADS1256 Features: - The complete ADS1256 application circuit module. - Onboard Boost boost circuit, 3.3V LDO and 5.0V LDO, can be externally powered from a single supply. - The power supply and digital level range: 1.8V - 5.5V (default 3.3V). - Onboard low temperature reference. - Single-ended or differential inputs can be used. Input attenuation can be configured. By default, there is no attenuation (partial pressure resistance air welding). - The onboard crystal frequency is 7.680MHz. - The analog signal input interface connector is MX3.0-16Pin. - Four-layer FR4 PCB board that complies with ROHS. Package Included: 1 x ADS1256IDB Analog to Digital Conversion Module
