ADS1115-ADC Module For Raspberry Pi 3 / 2 / B+

Description: The ADS1115 are precision analog-to-digital converters (ADCs) with 16 bits of resolution offered in an ultra-small, an MSOP-10 package. Data are transferred via an I2C-compatible serial interface, four I2C slave addresses can be selected, it operate from a single power supply at 3.3V. It can be used to detect analog signal and convert it to digital signal. You can attach a joy stick or other analog sensor such as NTC,temperature, dust sensor and so on. Features: Parameters Values Size 65.0mm x 30.0mm x 18.0mm Power Supply 3.3V Analog Input Voltage GND to VDD PROGRAMMABLE DATA RATE 8SPS to 860SPS INTERNAL LOW-DRIFT VOLTAGE REFERENCE INTERNAL PGA Available Resolution 16-bit I2C INTERFACE Pin-Selectable Addresses Channels Number 4 SINGLE-ENDED OR 2 DIFFERENTIAL INPUTS PROGRAMMABLE COMPARATOR 2/3 ~ 16 INTERNAL NTC Support Available Click to know more information Package included: 1 x ADS1115-ADC Module
