ADF4351 RF Sweep Signal Source Generator Board 35M-4.4G STM32 with TFT Touch LCD

Click here to download Manual ADF4350 ADF4351 password x12345678 NOTE The product is only included ADF4351 Features ADF4350 ADF4351 module is a senior engineer to build fully refer to the official version of the design PCB board has beautiful appearance reasonable layout and design standard materials The output frequency range 35M 4 4G Fractional N points frequency synthesizer and integer N frequency synthesizer VCO with low phase noise Programmable 1 2 4 8 16 divider output Mode of power supply 5V power supply can use the USB power supply directly Color screen display touch screen operation can realize frequency frequency sweep Chip Introduce ADF4350 ADF4351 combined with external loop filter and external reference frequency when using it can realize the decimal N points frequency or integer N frequency and phase lock loopfrequency synthesizer ADF4351 have an integrated voltage controlled oscillator VCO its fundamental wave output frequency range to 2200 MHz to 4400 MHz In addition the use of 1 2 4 8 16 points frequency circuit the user can generate as low as 35 MHz 137 5 MHz RF output frequency For the isolation of application the RF output stage can be mute Mute function can be controlled by pin can also be controlled by software At the same time provide auxiliary RF output and can be shut off when not in use Specifications Output Frequency Range 35M 4 4GThe Root Mean Square RMS Jitter Less Than 0 4 ps RMS Typical Power Supply Voltag
