ADC Module ADS1100 for Analog Signal Capture Converter Compatible M5StickC ESP32 Mini IoT Development Board Fi
M5Stack
sku: 1542063
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$10.99
Shipping from: China
Description
nullDescription ADC HAT is another type of C HAT specifically design for M5StickC controller Same as ADC unit this is an ADC converter component for stickc Packed with an ADC converter chip ADS1100 which is a fully differential 16 bit self calibrating A D converter Extremely easy to design with and configure the ADS1100 allows you to obtain precise measurements with a minimum of effort The ADS1100 consists of a A D converter core with adjustable gain a clock generator and an I2C interface ADS1100 itself is able to accept a differential input from 5 5 V but we have limited the input to 0 12V by adding on the peripheral circuit design of this IC Product Features M5StickC CompatibleInput 0 12VSoftware Development Platform UIFlow Blockly Python ADS110016 bits ResolutionCONTINUOUS SELF CALIBRATIONSINGLE CYCLE CONVERSIONPROGRAMMABLE GAIN AMPLIFIER GAIN 1 2 4 OR 8LOW NOISE 4μVp pPROGRAMMABLE DATA RATE 8SPS to 128SPSINTERNAL SYSTEM CLOCKI2C INTERFACE address 0x48Package Included 1x ADC HAT1x 2 Pin 3 96 Pitch TerminalApplication Analog Signal CaptureLinks Datasheet ADS1100Schematic EasyLoaderclick to download EasyLoader Code 1 forIDETo get complete code please click here Pin Map M5StickCGPIO0GPIO265VGNDHAT ADCSDASCL5VGND Video
