AD Collecting Acquisitions Card 8-Channel 30ksps Output Rate Data Acquisition Module 24-Bit For Factory

AD Collecting Acquisitions Card 8-Channel 30ksps Output Rate Data Acquisition Module 24-Bit for Factory Specification: Item Type:Data Acquisition Module Overview: ADS1256 8-Channel 24-Bit ADC Module Equipped with TI ADS 1256IDB Low Power Consumption High-Accuracy ADC Chip And 2.5V Reference Voltage Source Using SPI Interface Communication Protocol Data Output Rate up to 30ksps Support Single-Ended Input and Differential Input Interface Description: 5V GND: 5V Power Input SCLK DIN DOUT CS: SPI Communication Interface DRDY: ADS1256 Data in Order Output Active Low PDWN: ADS1256 Sync/Turn Off The Power Input Active Low AIN0-AIN7: Analog Voltage Input Configurable as 8 Single-Ended Inputs or 4 Differential Input Values The Measured Voltage Should be Shared with The Module The Third Group is The Difference Between AIN2-AIN3 Which are 2.5V 2.5V 0V and 2.5V for The Four Groups Package List: 1 x Module Note: Since the voltage of ADS1256 is 5V the measured voltage should be lower than the power supply voltage 2V so this module is only suitable for measuring analog voltages within 3V.
