AC85V-250V 315MHZ/433MHZ 1CH Remote Control Switch Module RF Wireless Transmitter Receiver Board For LED Smart Home

Features: The wireless remote control switch is designed with two working modes: manual and remote control. The button on the interface is the manual key and the learning button of the remote control. In the remote working mode, there are two working modes that can be adjusted (self-locking and interlocking) which can be switched through the learning button on the interface, and can be combined with any of the more than 10 wireless remote controllers. Technical Parameters: Working voltage: AC85-250V Load: 1000W Specifications: 55x51x25mm (including housing) Operating frequency: 315MHz / 433MHz (optional) Working mode: self-locking, interlocking (switching by learning method) Coding type :Learning code Remote control distance: 10-30M Working temperature: -60-50 (C) Usage: Self-locking learning code method: First, after the wireless remote control switch is powered on, connect an electric appliance to manually test whether the remote control switch is working normally. Then press and hold the learning button for about 3 seconds, the learning indicator light on the remote control switch interface is on, release the hand, immediately press any button on the remote control twice, the learning indicator flashes three times and then gray out, indicating that the learning is successful. Clearing method: (Please clear the code first and then correct the code when you need to change the working mode) Press and hold the remote control switch interface learning button for about 15 seconds. The learning indicator light is turned from off to off to indicate that the clearing code is successful. Interlock learning code method: 1. First, after the wireless remote control switch is powered on, connect an electric appliance to manually test whether the remote control switch is working normally. 2. Then press and hold the learning button on the remote control switch for about 3 seconds, the learning indicator on the interface lights up, release the hand, immediately press any button on the remote control (or unlock button) and then press another button (or lock button) on the remote control. 3. After the learning indicator flashes three times, it will be grayed out, indicating that the learning is successful. Package Included: 1 x Remote Control Switch Module 1 x 433MHz Transmitter
