9V-24V 30W Touch Switch Capacitive Touch Sensor Module LED Dimming Control Module

Parameter:1. Input voltage: 9v-24v2. Output voltage: 9v-24v3. Load power: 30W4. Load current: 3A5. Standby current: 10mA6. Standby power consumption: 0.1w7. Operating temperature: -20 ℃~ 65 ℃8. Type: Touch_S (L40W10)9. Size: 40mm * 10mm * 1.2mm(Note: test conditions Vin = 12V)Instructions for use:Module size 40mm * 10 * 1.2 (mm), for width = 10mm of the hard light or other lamps;Using a wide voltage work program, the input voltage 9V to 24V can be,Note that the output load voltage is approximately equal to the input voltage;Module anti-interference and self-adaptability is better, widely used in civilian hard-light type controlThe status of this version LED is always on.This series is a four-in-one version of the model,The default factory setting is one-way dimmingMode description:Touch_Sensor_S00 (general switch):S00 mode, fast touch switch lamp on / off state, no dimming function. Effect gradient.Touch_Sensor_S01 (Unidirectional dimming):S01 mode, fast touch switch lamps on / off state;In the case of open, long touch to enter one-way dimming(keep touching, dimming to maximum or minimum brightness, automatically stop dimming),Let go lock the brightness,The switching brightness is the last lock brightness.In the off condition, the long touch will be dimmedfrom the previous brightness to the brighter direction.Effect gradient.Touch_Sensor_S02 (Cycle Dimming)S02 mode, fast touch switch lighting on / off state;In the case of open, long touch into the cycle dimming (keep touching
