9-15V 180W Dual Channel Brush Motor Driver 12A 10K-30K Motor Driver Board

Features: Drive operating voltage 9-15V, support 9-12V voltage level DC brush motor Description: The dual-channel brushed-brush motor driver is designed to drive low-voltage DC motors with a continuous output of 12A per channel and a DC motor capable of driving up to 180W. The device timing in the driver is highly optimized, allowing the PWM input to have a minimum pulse width as low as 2us, which fully guarantees the dynamic adjustment range of the PWM and improves the control quality of the motor. Application: Automated robot Mechatronics Equipment manufacturing Electronic competition Scientific research, production Program control considerations: Drive frequency is 10K-30K (in Hz) When the drive motor 1 is rotated forward, please change the direction of motor rotation. Program design P1(0) P2(0) And add a delay (30ms ~ 40ms) delay to avoid dead zones when driving. The other is also set up. Interface Description: VCC Power output voltage: 5V GND Driver board ground P1, P2, P3, P4 PWM drive signal P1 interface Drive description: P1 P2 P3 P4 Motor status 0 0 0 0 Brake PWM 0 0 0 Motor 1 forward 0 PWM 0 0 Motor 1 reverse 0 0 PWM 0 Motor 2 forward 0 0 0 PWM Motor 1 reverse PWM 0 PWM 0 Two-way motor moving forward at the same time 0 PWM 0 PWM Two-way motor simultaneous motion reversal Package includes: 1 x Motor driver board
