8ch 4-20MA/0-10V Current Voltage ADC Collector Read Capture Module RS485 MODBUS RTU PLC Board

Modbus protocol CLICK HERE TO OPEN1 Product description 4 20MA 8ch 0 20MA current analog inputRS485 MODBUS RTU standard communication protocolNetted with configuration software PLC or industry touch panelCommunication circuit designed for thunder protection and interference immunityUsed for signal collection and control in industrial field2 Specification 4 20MA 1 Working voltage DC 7 25V 9V 12V 24V 2 Working current 8 50MA3 8 channel current input the input current range of each channel is 0 20MA 4 20MA4 RS485 communication isolation protection 3000VDC5 Standard MODBUS RTU command function code 06 16 Write 04 03 Read 6 Baud rates 1200 2400 4800 9600 default 19200 38400 57600 1152007 Parity bits None default Even Odd8 Installation method Standard DIN rail installation9 Dimensions 125 70 30mm10 Weight 114 grams3 Interface definition 4 20MA VCC Power input GND Power input AI1 Current input channel 1AI1 Current input channel 2AI2 Current input channel 3AI2 Current input channel 4AI3 Current input channel 5AI3 Current input channel 6AI4 Current input channel 7AI4 Current input channel 8A RS485 signal A B RS485 signal B 1 Product description 0 10V 1 Product description8 channel analog inputRS485 MODBUS RTU standard communication protocolNetted with configuration software PLC or industry touch panelCommunication circuit designed for thunder protection and interference immunityUsed for signal collection and control in industrial field2 S
