800TVL Mini Door Eye Hole Camera CCD Fisheye 1.7mm Wide Angle Lens Peephole Door Camera

Features : CCD, 800TVL. BNC+DC output. Mini Door Eye Peephole camera. Wide angle 1.7mm Lens. View Angle is around 170-178 degrees. Internal synchronization system. Mini size. Specification : Sensor 1/3'' CCD Horizontal resolution 800TVL Lens 1.70mm wide angle lens TV system NTSC/PAL Effective pixels 1080(H)x582(V) Scanning system 2:1 interlace Minimum illumination 0.5Lux F2.0 Video output 1.0VP-p VBS75 Built-in AGC YES S/N Ratio 50db White balance automatic (2,800 to 8,200 degrees Kelvin) Auto electronic shutter PAL:1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Power supply 12V DC (90mA) Built-in audio No Operating temprature -10 to +50 Dimension 21mm Weight 200g Installation Method: Step 1. Connect the power adapter to the camera Step 2. Connect the BNC output to BNC input Package includeds : 1 x 800TVL Mini Door Eye Hole Camera Details pictures :
