80 Channels HDMI to DVB-T Modulator HDMI Extender Over Coaxial

The HDMI To DVB-T Modulator can convert HDMI signal to HD digital TV signal based on DVB-T CATV transmission mode. The product applies RF modulation technology characteristic to realize the HD signal to HD digital TV signal conversion and transmit via coaxial cable over long distance up to 500 meters.
Features
Supports a HDMI input and a F type/BNC RF output.
Support HDMI resolution up to 1080P/60Hz.
Output signal accord with the relevant DVB-T standards, and it can be compatible with any DVB-T TV or receiver.
Transmission distance up to 500 meters by SYV-75-5 coaxial cable and no need amplification.
Support 80 channels for option and frequency ranges 139MHz-950MHz.
Products using the broadcast signal transmission mode, only one line can transmit 48 channels of high-definition video signal at the same time.
By a CATV network mixer, the Modulator over Coaxial cable supports pair to pair and multiple to multiple video matrix.
The use of digital TV communication protocol, anti interference and error correction capability is very strong.
Installs in minutes. The use of the existing CATV transmission network, no need wiring.
By using a special receiver (HDEX009M1), you can decoding DVB-T signal and output HDMI HD signal for non DVB-T TV/Monitor.
Specifications
Interfaces Power LED indicator, HDMI LED indicator, HDMI IN, DC 5V Jack, CHANNEL, RF OUT
Package Contents 1 x HDMI To DVB-T Modulator, 1 x AC Power Adapter, 1 x User Manual
