5pcs Mini 12V 20A Digital LED Dual Display Timer Relay Module With Case Timing Delay Cycle

5pcs Mini 12V 20A Digital LED Dual Display Timer Relay Module With Case Timing Delay Cycle
Eachine1
sku: 1384506
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$25.99
Shipping from: China
   Description
Specifications 1 Timing Range 0 999s 0 999min 0 999h2 Appearance Size display board 48mm 29mm installation 45 5mm 26mm3 Function Setting 18 kinds combination function4 Relay 20A power 1800W5 System Power 12V Features 1 Double LED Display can set two sets timing time Timing time T1 timing time T22 Three Timing Time Chosen 0 999s 0 999min 0 999h3 Operating Mode Setting Delay Timing LoopInstructions for use 1 Connect the circuit diagram according to the circuit diagram2 After the power is turned on the default is the working interface there are two sets of time for the user to set Short press set to enter the time setting mode At this time the digital tube will flash Pass Set time T1 press again set to set time T2 after setting press short again set to save Set the data or wait for the 6S system to automatically save the data 3 Long press set enter the parameter setting interface the default is P0 0 you can set P0 by P0 0 means that the timing range is secondsP0 1 indicates that the timing range isP0 2 indicates that the timing range is time P0 setting is completed short press set to switch to P1 the same method to set P1 P0 timing range P1 working mode P1 0 mode after delay T1 time relay will operate T1 timing P1 1 mode after delay T1 time relay will not operate T1 timing P1 2 mode after delay T1 time relay will operate T1 timing after delay T2 time relay will not operate T2 timing endP1 3 mode after delay T1 time relay wi
