5pcs CE032 DC 5V 6V 9V 12V Motor Reversible Controller Time Adjustable Delay DPDT Relay Switch 2A 5000S

Specifications Operating voltage DC 5 12V 5V 6V 9V 12V Operating current 5V forward 4ma reverse 36ma 12V Forward 6ma reverse 44ma Load voltage DC 1 48V OR AC 85 265VLoad current Maximum 2AForward maximum time 5000 seconds 0 1 seconds stepReverse maximum time 5000 seconds 0 1 seconds stepBy Time multiple selection setting The maximum delay of up to 40 thousand seconds short circuited pad Size 54 x 22 x 15 mmHow to Use VIN connected to the positive of power supply GND connected to the negative of power supply P connected to the positive of Motor power supply P connected to the negative of Motorpower supply M M are connected to both ends of the motor After power D1 flashes 3 times D2 off M output positive M output negative motor forward after a time delay T1 D2 on M output negative M output positive motor reversal after a time delay T2 D2 off M output positive M output negativ motor forward and so on T1 indicates motor Forward delay time default 0 1 5000 seconds adjustable step 0 1 seconds T2 indicates motor Reverse delay time default 0 1 5000 seconds adjustable step 0 1 seconds   By Time multiple selection setting The maximum delay of up to 40 thousand seconds How to Set Up 1 After power D1 3 blinks Enter the work mode D2 on Reversal D2 Off Forward2 Press and hold the Key for 2 seconds D1 on enter the setup mode D2 off It s forward setup mode 3 In forward setup mode the continuous trigger KEY twice D1
