5V 12V 24V 2 Channels Multi-function Relay Module/Time Delay/Self Lock/Cycle/Timing Relay Module PLC Control

Module function The user can select one of the following 20 functions by pressing the button and display and can set and save the function parameters and also view the parameters of the current function The time parameter setting is adjustable by 0 1 second at minimum and the precision is better than 0 01 second Instructions for setting up can be obtained from your dealer Tips Function 1 8 is powered on automatically function 9 18 requires a high level pulse signal high level duration is not shorter than 20ms the same below triggers the start function 19 20 requires a continuous high level Function 1 Timing pull in After power on the delay T1 time relay is closed T1 is adjustable between 0 1 seconds and 270 hours and a high level pulse signal is sent to the CH1 interface repeating the above functions Function 2 Timing disconnection the relay is closed when power is on the relay is disconnected when the time delay T1 T1 is adjustable between 0 1 seconds and 270 hours and a high level pulse signal is sent to the CH1 interface and the above functions are repeated once Function 3 Timing pull in and then disconnect After power on the relay does not pick up first After the delay time T1 arrives the relay pulls in after the pull in time T2 arrives the relay is disconnected and the delay time T1 and T2 is between 0 1 seconds and 270 hours Adjustable between the two give the CH1 interface a high level pulse signal repeat the above functions Functio
