5Pcs ESP-12N ESP8266 Remote Serial Port WIFI Wireless Module

Product Description: ESP-12N is encapsulated by the high performance chip ESP8266EX. The chip is encapsulated a advanced Tensilica's L106 32-bit MCU, with 16-bit short mode, basic frequency support 80 MHz, 160 MHz, supports RTOS. ESP8266EX has the full and complete WiFi fuction, which can used independently and alsoused as a slaver with other Hoster MCU, which can start directly from the out-built Flash. In addition, the built-in high-speed buffer is helpful for the system performance. Especially, ESP8266EX can be used as a WiFi adapter by SPI/SDIO and/or I2C/UART interface, when it is applied to the other MCU design. SOC characteristics: Built-in Tensilica L106 ultra-low power 32-bit CPU, main frequency supports 80MHz and160MHz, and RTOS; Built-in TCP/IP protocol; Built-in one-channel 10-bit high precision ADC; Outboard interface: HSPI, UART, I2C, I2S, IR Remote Controk, PWM, GPIO; Deep sleep current is 10uA, the cut-off current is smaller than 5uA; Wake,connect and transmission data package within 2ms; The consume power is smaller 1.0Mw (DTIM3) when at stand by status; Built in 1M byte for SPI Flash. WiFi characteristics: Support 802.11 b/g/n/e/I; Support Station, Soft AP, Soft AP+STA mode; Support WiFi Direct (P2P); Support CCMP (CBC-MAC, computation mode) TKIP (MIC, RC4) WAPI (SMS4) WEP (RC4) CRC etc. for hardware acceleration. P2P finding, P2P GO mode/ GC mode and P2P power manage WPA/PA2PSK and WPS; 802.11 security certification: pre-certification and TSN Support 802.11n (2.4GHz); 802.1h/RFC1042 frame encapsulation; Support seam less roaming; Support AT remote update and cloud update (OTA); Support Smart Config function (including Android and Ios device). Module interface: 2* UART; 1*ADC; 1*En; 1*wakeup pin; 1*HSPI; 1*I2C; 1*I2S More than 10*GPIOs Working temperature: -40-+125; Module size: 16mm24mm Application: Electronical appliance; Smart power plug, smart light; Infant monitor; Sensor networks; Security ID label; Wireless location beacon; Home automation; Mesh networks; IP video camera; Wearable electronics; Wireless location recognition; Industrial wireless control; Package included: 5 x ESP-12N ESP8266 Remote Serial Port WIFI Wireless Module
