5PCS Beitian BS-280 232 GPS Receiver Module 1PPS Timing With Flash + GPS Antenna

Description: 232 level output, 9600, 1HZ output, standard NMEA-0183 protocol output. Parameter Description Chip characteristics Chip U-blox U7 Receiving mode GPS, QZSS, WAAS, SBAS, EGNOS, MSAS Frequency GPSL1, SBAS L1 Channel 56 search channels Sensitivity Track -162dBm Recapture -160dBm Cold start -148dBm Precision Horizontal accuracy 2.0 m CEP 2D RMS SBAS assist (open space) Speed accuracy 0.1m/s 95% (SA off) Time accuracy 1us Start Time Cold start 29s Warm start 25s Hot Start 1s Output Data Baud rate 4800bps-921600bps,default 9600bps Output level TTL or RS232, default RS-232 level Output protocol Default NMEA-0183 protocol Standard GNSS 1Hz-10Hz, default 1Hz Work limit Height 50,000m maximum Speed 515m/s maximum Gravity acceleration 4g maximum Power consumption Voltage DC 3.6V-5.5V, typical: 5.0V Current Normal 45mA@5.0V Physical parameter Size 28mm*28mm*8mm Weight 11.5 grams Line length 2m Connector 1.25 pitch 6pin socket Surroundings Operating temperature -40 C ~ +85 C storage temperature -40C ~ +85C Indicator light TX light Power-on blue light flashes to indicate that there is data output. PPS light The light is not lit when it is not positioned. After 3D positioning, it starts to blink. The pins of the module are: 1.PPS, there is a second pulse output after positioning, the pulse period is 1s, and the high level lasts for 100ms, which is used for system synchronization. 2. GND, ground. 3.TX, the data output of the module. 4.RX, the data input of the module. 5.VCC, 3.6-5.5V, recommended 5.0V. 6. BOOT, please hang out during normal work. Package included: 5 x Beitian BS-280 232 GPS Receiver Module 5 x cable
