5A Monophase Active Output AC Current Transformer Module

Features 1 On board precision micro current transformer2 On board high precision op amp circuit to do accurate sampling and appropriate compensation and other functions to signal3 The module can measure AC current within 5A corresponding output analog can be adjusted4 Under ideal conditions the input voltage VCC is 3 35V according to the potentiometer adjust the amplification ratio amplification range 0 100 times to adjust the required output voltage but the output OUT of the maximum voltage does not exceed 1 2 VCC 5 The output signal is the AC voltage signal and the output signal voltage does not exceed the maximum 1 2VCC 6 PCB board size 38 mm x 18 5 mm Specification Rated input current 5ARated output current 5mAChange 1000 1Phase difference rated input 20 100 Linearity range 0 10A 100 Linearity 0 2 Precision rating 0 2Isolation voltage uses 3000V measurementSealing material Epoxy resinOperating temperature 40C to 70CPackage included 1 x Current Transformer Module
