5A Dual Way DC Motor Drive Module Remote Control PWM Speed Regulation Board, 501 Original

Feature:1. Two motors can be independently controlled, each can output current 5A, crest value 9A, standby current only 10uA.2. Wide power supply range 3-14V, signal power supply range 2.2-6V, 3.3V and 5V levels can be satisfied.3. The board provides 3.3V 100mA power supply for your control system. It can also be equipped with 433M wireless module remote control motor or other loads.4. Two H-bridge motors can drive two DC motors or one 4-wire two-phase stepping motor at the same time.Specification:Module supply voltage: 3V-14VSignal input voltage: 2.2-6V, supporting 3.3V and TTL levelSingle working current 5A, crest value current 9A, low standby current (less than 10uA)Installation hole diameter: 2mmSize: 38mm*27mm*14mm/1.49*1.06*0.55''Weight: 14gNote: Please allow 1-3mm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.1 X 5A Dual Way DC Motor Drive Module
