4S Series 16.8V 14.8V Lithium Battery Protection Board 100A With Balance Inverter Board

Description The module has the functions of over charge protection over discharge protection and short circuit protection Safety and reliability Battery heating in use means that battery rate is not applicable This situation can not be used for a long time and the battery will be damaged quickly There are 10 MOS transistors strong heat dissipation aluminum sheet upper limit of continuous current 100A Suitable for 4 series battery packs such as inverter a xenon lamp solar street lamp etc Current 100 120ACharging Voltage 16 8VCharging current 10A Max Balanced Current of Electricity 45mAWorking temperature 20 80 degree CDimension 70 x 60 x 8 5 mm ItemSpecificationUnitRemarkCurrentContinuous discharge current100AAttention temperatureInstantaneous discharge current120A ChargingCharging voltageLithium battery charger 16 8VVSwitching power supply 17 18VCharging current10 max A Overcharge protectionOvercharge detection voltage4 28 0 05VSingle coreOvercharge protection delay0 5S Overcharge release voltage4 08 0 05VSingle coreBattery balancePower balance detection voltage4 20 05V Power balance release voltage4 20 05V Battery balance current45mA Over discharge protectionOver discharge detection voltage2 50 08V Over discharge detection delay0 1S Over discharge release voltage2 90 1V Overcurrent protectionOvercurrent detection voltage150mV Overcurrent detection delay40mS Overcurrent protection current12010A Overcurrent protection release conditionDisconnect load
