48V Wind Generator Controller 500W Wind Turbine Generator Controller

Package list 1x Controller Specifications Rated battery voltage 48VWind generator braking voltage 60VWind generator recover voltage 54VProtection class IP67 Precautions 1 Verify that the wind turbine output voltage matches the rated voltage of the battery 2 Wire in the following order first connect the positive and negative terminals of the battery and then connect the three phase voltage output of the fan 3 Please carefully connect the battery and the wind turbine to the controller according to the instructions Connecting the reverse polarity or the wrong position will cause the system to work abnormally and may even cause damage to the system components 4 Although the controller has taken protective measures against various possible accidents it is strongly recommended that users strictly abide by the operating procedures to prevent damage to the battery and controller Wiring 1 Connect the and of the battery to the positive and negative terminals of the battery of the controller 2 Connect the three phase output voltage of the wind turbine to the three phase voltage input terminal of the controller fan 3 When manual brake is required short the red thin wire to the positive battery that is complete the manual brake function To cancel this function just disconnect the thin red wire Indicator status When the controller green power BATTERY indicator is on it indicates that the battery is connected properly When the controllers green fan access W
