48V LED Battery Indicator Gauge Meter For Golf Cart ATV Boat

48V LED Battery Indicator Gauge Meter For Golf Cart ATV BoatDescription:High reliabilityLED Flash for low chargeMemory option to recall last charge level10 segment LED Bar Graph displaySilent opration, no moving partsRelay out put enable optionFits standard panel cut-outWide operating temperatue rangeSpefication:Color: BlackMaterial: PlasticSize: Show as the pictureDistance between holes: 44mmCapacity: 1 Red, 2 Yellow, 7 Green color LED for indicatorResolution: 10% per LED segmentOperating Voltage: 48VOperating current: 20 mA nominalStorage and Operating: -20? to +85?Accuracy: +/- 0.5%Connection: (3-pin)Pin(+): Battery +Pin(-): Battery -Pin(C): single output for external useCase Style: Front panel mountFunction:1. Scan from "F" to "E" when connected with power.2. Display "F" green light when first use.3. Battery charge capacity is indicated using a 10 segment LED bar graph display form full to empty.4. The LED display will delay 155s when the battery's capacity is down.5. The 2nd LED from the left flashes as a warning that the battery has discharged 80%.6. At 90% discharge, LED alternate flashes the left 2 LED's to indicate very low capacity is remaining.7. Recognition fales battery charging signals function: Only when battery charging higher than definitevoltage and last more than 6 minutes can it be recognized to full battery.8. About the "C" pin (optional): when the switch is off, LED will turn off, and the indicator will not work.Fitment:Works with 48V Lead-Acid Batteries in Golf Carts, Forklifts, Trucks, RV's, ATV's, UTV's, Scooters, Boats and MoreNote:1. Please check the size measurement carefully before making payment.2. Please allow 0.5-1 inch difference due to manual measurement.(1 inch=2.54cm)3. The color of the actual items may slightly different from the listing images due to different computer screen, thanks for your understanding.4. Professional Installation Is Highly Recommended!Package Inlcuded:1 X 48V LED Battery Indicator Gauge1 X User Manual
