433MHz 4CH Channel Remote Control Switch Module Learning Code DC12-48V 180-700W 30A Four Way Relay

Product Introduction The remote control switch adopts 30A relay which can load high power electric appliances The receiving mode is decoding of learning type single chip microcomputer It can learn multiple remote controllers and each remote control can learn by pressing buttons Each remote control controls multiple switches A plurality of remote controllers can be used to control one switch and the operation is simple and flexible and the remote control has different working modes for each button thereby avoiding the trouble of switching the output mode by jumping the cap and is convenient to use and is suitable for multiple uses in various fields The output switch signal is easy and convenient to install Mainly used in lamps electric doors windows lifting equipment water pump lift control security industry and agricultural watering and other remote wireless remote control etc It has the advantages of easy installation simple and safe to use Product Parameters 1 Working Voltage DC12 48V2 Working Frequency 433MHZ3 Working Temperature 40 85C4 Receiving Sensitivity 105dBm5 Load NO 30A 240VAC NC 20A 240VAC 6 Circuit Board Size 122x87x17 mm 7 Shell Size 144 8x91x40 mm Working Way Press A data bit 1000 to learn the controller is joggedPress B data bit 0100 to learn the controller is interlockedPress C data bit 0010 to learn the controller is self lockingPress D data bit 0001 to learn control relay 1 2 jog relay 3 4
