433MHz 12V 2CH 2 Channel Wireless Remote Control Switch + 2 Button Transmitter Learning Code Jog Self-locking Interlock

If you need more Transmitter please buy Product ID: 1499472 Output method: A. Non-locking - the default working mode, the work switching jumps without inserting; B. Self-locking - connect 1 and 2 positions with a shorting cap C. Interlocking - connect 2 and 3 positions with a shorting cap Learning/clearing methods and steps: 1. Press the learning button, the indicator light is off, then release, press any button in the remote control within 6 seconds, the indicator light flashes four times and then lights up continuously, indicating that the learning is successful; 2. Can learn more than 20 different address codes of the 2262 chip, 1527 chip and other wireless remote control of the same frequency; 3. Clear: Press and hold the learning button about 8 seconds, the indicator light from off to light, indicating that all the saved information has been successfully cleared. Introduction: The wide voltage single-channel controller is a user-friendly, idealized practical wireless control device based on user requirements. Learning function, single-chip decoding is convenient for customers to support a variety of remote controls. The three working modes are freely set for users to use for different control functions. The input voltage range is wide, the output is charged, and the output switching signal is more convenient for users to use in different occasions, which increases the application flexibility of the product. It can be applied to the field of lighting, motor shut-off, security industry machine wireless remote control lamp, with the advantages of convenient installation, simple and safe use. Feature: 1. Working voltage: DC12V 2. Quiescent current: 8mA, Single working current: 40 mA, Two working current (self-locking): 80 mA 3. Working temperature: -10C to + 60C 4. Receiving sensitivity: -105dBm 5. Working frequency: 433MHz 6. Output voltage: AC, DC optional 7. Output current: 10A 8. Size: 72 x 52 x 26mm 9. Remote control battery: L828/12V, 27A (includes) Package includes: 1 x Receive module 1 x Remote control
