4 Square 12AWG 30A 1/3/5Meters Length Solar Panel Series Parallel Cable With MC4 Connector

Features: - Compatible Mc4, Male Female 1 to 3 Wire Connector. - Lower contact resistance. - Strong pulling force capability. - Created seal, design of dust proof. - With convenient installation, strong commonality. - Double seal rings to better waterproof effect. - Compatible with PV cables with different insulation diameters. - With excellent aging resistance and UVendurance. - Load capability with big current and high voltage. - Quick & simple assembly processing and simple removal of plugs without the aid of any extra instrument. - Resistance of extra high & low temperature and fireproof. - With the capacity of anti-aging and resistance to ultraviolet radiation on the out cover. Specifications: MC4 connector MC4 connector Operating current: 30A Voltage resistance: DC1000V Contact resistance: 500 m Cable diameter: 5 mm ~ 7 mm Ambient temperature: -40 ~ + 105 Protection level: IP67 Level of security: Insertion force: 50N pull-out force: 50N Insulation material: PPO, black Contact parts: copper cn, nickel sn plating Flame retardant: ul94-vo Terminal connection: pressing Line length: 1 m, 3 m, 5 m Extension Cable 4 mm2 12AWG Package included: 1 x Solar Panel Extension Cable
