4 Digit 7-Segment 0.56' LED Display Tube Decimal 7 Segments HT16K33 I2C Clock Double Dots Module

Manual Click here to openFeatures These 7 segment displays normally require 13 pins 5 characters and 8 total segments each Solves the annoyance of using 13 pins or a bunch of chips by having an I2C constant current matrix controller sit neatly on the back of the PCB The controller chip takes care of everything drawing all the LEDs in the background All you have to do is write data to it using the 2 pin I2C interface There are three address select pins so you can select one of 8 addresses to control up to 8 of these on a single 2 pin I2C bus as well as whatever other I2C chips or sensors you like The driver chip can din the entire display from 1 16 brightness up to full brightness in 1 16th steps It cant din individual LEDs only the entire display at once Size 5 03 x 2 68 x 1 2 cm 2 x 1 1 x 0 5 inchPackage Included 1 x 4 Digit 7 Segment 0 56 LED Display Tube
