3pcs XH-W1316 Thermostat Control + Acceleration 2 Relay Temperature Controller DC24V High and Low Alarm Controller

Parameters Product Name Microcomputer digital temperature controllerSpecification model XH W1316Temperature control range 50 110CTemperature measurement accuracy 0 1CRefresh rate 5 times per secondInput voltage DC 24VMeasurement input 10K 3950 NTC waterproof sensorSide output Two way relay outputSize 82 x 58 x 30mmCodeCode descriptionSetting rangeFactory settingP1Operating modeC HHP2Backlash setting0 30C2P3Temperature difference setting5 50COFFP4Setting range upper limit 45 110C110P5Setting range lower limit 50 105C 50P6Temperature correction 7 7C0P7High temperature alarm 50 125COFFTo set the values of F3 and F7 you need to set it to ON first then press the set button to enter the setting F1 working modeH indicates that the current work is in the heating mode C indicates that the current work is in the cooling mode F2 Hysteresis settingHysteresis temperature control maximum minimum Example need to control the temperature of 35 40 then the difference is 5 40 35 5 so the hysteresis is set to 5 F3 Temperature difference settingA set of temperature difference can be set When the first level red light is on the difference between the real time temperature and the stop temperature is greater than the set value of F3 At this time the second level red light is on and two devices are activated When the difference between the real time temperature and the stop temperature is less than the set value of F3 the second level red light do
