3pcs CP2112 USB to SMBus I2C Module USB to I2C IIC Communication Board CCS811 Debugging Board Sensor Controller

3pcs CP2112 USB to SMBus I2C Module USB to I2C IIC Communication Board CCS811 Debugging Board Sensor Controller
Eachine1
sku: 1605797
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$28.99
Shipping from: China
   Description
Features The CP2112s highly integrated USB to SMBus bridge controller integrates a USB 2 0 full speed function controller USB transceiver oscillator and eight GPIO pins All customization and configuration options can be selected through a simple GUI based configurator Standard HID class devices do not require the development of complex firmware and drivers The CP2112 device enables fast USB connectivity with the minimal development effort Parameters USB bus power supply 4 0 to 5 25VSelf powered 3 0 to 3 6VI O voltage 1 8V to VDDWorking environment temperature 40C 85COn chip power on reset circuit on chip voltage regulator 3 45 V outputCompliant with USB specification 2 0 standard full speed 12Mbps USB suspend status via SUSPEND and SUSPEND pinsIntegrated 194 byte one time programmable ROM for storing customizable product information512 byte SMBus data buffer configurable clock speed device address 7 bit value is the slave address of CP2112Windows Mac and Linux HID to SMBus libraries API for rapid application development open access interface specifications 8 GPIOs can be configured as input output and open drain push pull configurable clock output for external devices 48MHz to 94kHz switching LEDs during read write SMBusModule size 29 5mm 21 3mm with two M3 mounting holes one MicroUSB female portApplication areas Portable controllers USB dongle data loggingPackage includes 3 x USB to I2C Communication Board
