3pcs 2 Channel Multi-function Module Delay Self-lock CycleTiming Timer 24V

Features The user can select one of the following 20 functions by pressing the button and display and can set and save the function parameters and also view the parameters of the current function The time parameter setting is adjustable by 0 1 second at and theis better than 0 01 second Instructions for setting up can be obtained from your dealer Load capacity Normally open portload capacity DC 0 30V 10A AC 0 250V 10ANormally closed portload capacity DC 0 28V 10A AC 0 125V 10A Detailed Function Click here to openTips Function 1 8 is self starting when it is powered on Function 9 18 requires a high level pulse signal high level duration is not shorter than 20ms the same below triggers the start and function 19 20 requires a continuous high level Module interface Module control terminal 1 DC power supply positive 24V modules 2 DC DC power supply negative3 CH1 Input detection interface 1 active high4 CH2 Input detection interface 2 active highoutput 1 NO1 Thenormally open interface 1 theis suspended before the suction and it is short circuited with COM1 after the suction 2 COM1 Common Interface 13 NC1 normally closed interface 1 shorted to COM1 before theis closed suspended after suction4 NO2 Thenormally opens the interface 2 theis suspended before the suction and the short is connected with COM2 after the suction 5 COM2 Common Interface 26 NC2 Thenormally closes the interface 2 and theis short circu
