3V Single-way Relay Module 1-way High-level Trigger Current Conversion Board for arduino Microbit
Keyes
sku: 1958407
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$3.99
Shipping from: China
Description
Introduce This is a commonly used single channel relay module which mainly uses HK4100F DC 3V SHC relay components It is usually used in automatic control circuits and it is actually an automatic switch that uses a small current to control the operation of a large current Therefore it plays the role of automatic adjustment safety protection and conversion circuit in the circuit The relay has 3 green binding posts for external circuits which are NO COM and NC terminals screen printing on the back When the relay is not connected to the control signal the COM terminal and the NC terminal are connected and the COM terminal and the NO terminal are disconnected When controlling we connect GND to the MCU GND VCC to the MCU 3 3V and S to the MCU digital port When the S signal terminal is set to a high level the relay is turned on the COM terminal and the NC terminal of the relay are disconnected and the COM terminal and the NO terminal are connected when the S signal terminal is set to a low level the relay is closed the relay COM terminal and the NC terminal are connected and the COM terminal is connected terminal and NO terminal are disconnected At the same time the module comes with two positioning holes with a diameter of 3mm which is convenient for you to fix the module to other devices Specifications Working voltage DC 3 3VRated current 50 120mACoil impedance 25 60ΩMechanical life 100 000 times under no loadElectrical life 3A 250VAC Cosφ 1 1
Price history chart & currency exchange rate
