3S 11.1V High Current 100A 3.7V Lithium Battery Protection Board With Balance

3S 11.1V High Current 100A 3.7V Lithium Battery Protection Board With Balance
Eachine1
sku: 1321938
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$7.58
Shipping from: China
   Description
Description: Model: HX-3S-F100A Overcharge voltage range: 4.28v0.05v Size: 70*60*8.5mm Over-discharge voltage range: 2.50.05v Upper limit working current: 100A (pay attention to heat dissipation) Working temperature: -40~+50C Upper limit instantaneous current: 100-120A Storage condition: -40~+80C Quiescent current: less than 30uA Effective life: more than 30,000 hours Internal resistance: less than 300m Short circuit protection: protection, delay self-recovery. Equilibrium current: 65 mA Charging voltage: 12.6V-13V Charging current upper limit: 10A T point description: Add a normally closed temperature sensing switch to extend the temperature protection. The 0R resistor next to the solder joint should be removed. Note: For discharge products above 3A, the discharge rate of the battery should be more than 3C. Magnification calculation formula: 1C rate battery, 2000 capacity is equal to 2AH*1=2A working current. 3C rate battery, 2000 capacity is equal to 2AH*3=6A working current. Note 1: Strictly according to the diagram wiring 0V (B-) 3.7V (B1) 7.4V (B2) 11.1V (B +) C-charge negative, C + charge positive, P- output negative P + output positive, do not Deliberate short circuit. Note 2: After the line is connected, it needs to be charged before it will have output. Note 3: When connecting 3 sets of batteries in series, please ensure that the voltage of each set of batteries is the same. If they are different, please fill each set of batteries separately and use them in series. In the discharge test, the battery with a fast voltage drop is a poor battery. Explain: Do not mix good and bad batteries together. There are 10 MOS tubes, strong heat-dissipating aluminum sheets, and the continuous current limit is 100A. It is suitable for 3 series lithium battery packs such as inverter, xenon lamp and solar street lamp. Package included: 1 x 3S 11.1V High Current 100A 3.7V Lithium Battery Protection Board With Balance
