3Pcs T2310 AC110V 220V Programmable Digital Time Delay Switch Relay T2310 Normally Open Timer Control Module 0-999S/Min/

Feature Independent crystal oscillator more accurate timing1 Convenient direct output wiring2 Add buzzer and audible alarm3 Add pause button to stop urgently5 Start and stop setting mode provincial conversion which is more convenient6 Automatically save when power off run automatically when power on7 Timing units can be set separately with 36 working combinations8 Timing range 0 999 seconds minutes hours9 To count in minutes or hours the digital tube flashes in seconds Note This product is a countdown operation and cannot be set to a 24 hour working mode Specifications Controller typeNormally open time controllerOperating VoltageDC12VDC24VAC110 220VControl circuit voltageDC12VDC24VAC110 220VRelay carrying power240W480W10A max Recommended power Relay carrying power 80 Relay typeNormally open relayPower consumption 1WRelay service life100000 TimesTiming error±3s in 24 hours Weight65g 1pcs Size67mm 45mm 34mmFixed wayEmbedded Hole 63mm 42mmOperation Introduction 1 In the conventional interface long press the SET button for 10 seconds to enter the setting mode the red digital tube displays the code and the green digital tube displays the code parameter value press the SET key to switch the code and press the up down keys to modify the parameter value 2 Adjust the value of P0 and P1 to 0 time unit is second 3 Adjust P2 to 5 the relay is closed first and then opened and continuously circulates4 Wait for 10 seconds to automatically save the settings af
