37GB-545 DC 12V 70RPM Gear Reducer Motor with Encoder Geared Reduction Motor

Descriptions 37GB 545 DC 12V micro gear reduction motor with encoder speed dial reducer Specification Voltage DC 12VSize approach Output Shaft Dia 6mmAxis Length 12mmAxle Shaft Length 21mmApplications For intelligent self balancing double balanced two wheeled vehicles smart home appliances robots camera rocker electric paper cutting paper machines etc Wiring Red Motor power positive change can control motor forward and reverse Black Code power negative positive and negative can not be connected incorrectly 3 3 5V Yellow Signal feedback 11 signals from the motor Green Signal feedback 11 signals from the motor Blue Encoder power positive positive and negative can not be connected incorrectly 3 3 5V White Motor power negative change can control motor forward and reverse Parameter Voltage RATIONo loadRated loadStall Current A Speed rpm ±10 rpmTorque kg cm Speed rpm ±10 rpmCurrent A Torque kg cm Current A L Size mm DC 12 0V1 90≤0 2707 258≤1355 024Features All the gear of metal mechanismWear resistance strong resistance to torsion smooth transmission compact structure D shaped double axisD shaped double shaft excellent thermal conductivity Hall D type encoder 3 layer high density molecular coating effectively isolates dust and has 10 times the life expectancy of ordinary layers Frequent blocking or frequent start up and upset are not recommended in the process of use which will significantly reduce the service life Package Incl
