360 Degree Rotary Encoder Module For Arduino Encoding Module

Functional characteristics and technical parameters: 1)Nominal voltage: DC 5V 2)Wire A, B: 0.5mA (Max 5mA; Min 0.5mA) 3)Common wire: 1mA (Max 10mA; Min 0.5mA) 4)Temperature range: -30 to+80 5)Output signal: A B phase position output square wave, when clockwise rotation, A phase position pull ahead B phase position 90 when anti-clockwise, B phase position pull ahead A phase position 90 . Size: 27mm*24mm Pin introduction: (1)2P port: VCC (DC 5V) GND (2)3P signal output port: A phase position, B phase position, C(GND). Package included: 1 x 360 Degree Rotary Encoder Module For Arduino
