35MHz~4400MHz OLED Display RF Signal Generator ADF4351 Module Sweeps Frequency Generator PLL

35MHz~4400MHz OLED Display RF Signal Generator ADF4351 Module Sweeps Frequency Generator PLL
thumb
thumb
thumb
thumb
thumb
thumb
thumb
thumb
TOMTOP
sku: E16218
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
€ 64.66
Shipping from: China
   Description
Features:
The main control adopts STM32F103C8T6, fractional N divider frequency synthesizer and integer N divider frequency synthesizer PLL-ADF4351 PLL.
The output frequency ran-ge is 35MHz~4400MHz, the main board adopts four-layer gold precipitation process, finecomponent selection, classic layout and wiring printed circuit boarddesign, making the signal output extremely stable, phase noise to meet the official design requirements.
On-board 25MHz active SiTime crystal oscillator, and reserved external clock interface, MCU ADC interface. Simple five-key operation design, clear logic, can set the point frequency, sw-eep mode output, sw-eep frequency step and sw-eep cycle can be adjusted.
Programmable SiTime crystal oscillator, reserved for external clock.
Five-way navigation button, easy to operate, and with CH340C serial chip, serial communication and firmware download can be realized.
   Technical Details
categoryName: Test Instruments & Tools > Electrical Instrument > Other
OriginalPrice: 64.66
product_availability: in stock
Warehouse: CN
