32x32mm PCB EFFIO-E 1/3" Sony Super HAD CCD ICX811 image sensor CXD4140 CCTV camera board module
Technical Details
| Audio Output: | None |
| Brand Name: | HASecurity |
| Color: | GREEN |
| Connectivity: | Closed System/CCTV Wired |
| Dimensions L x W x Dmm: | 32 x 32 mm PCB size |
| DSP / ISP: | SONY Effio-E CXD4140 chipset |
| High Definition: | 480P(SD) |
| image sensor type: | 1/3" SONY Super HAD CCD ICX811 |
| Installation: | Embedded |
| IR Distancem: | No |
| is customized: | No |
| Lens mm: | without LENs |
| Minimum IlluminationLux: | 0.01 LUX |
| Model Number: | Effio-EC4 |
| Network Interface: | None |
| Operation Temperature: | -0C ~ +50C |
| Power ConsumptionW: | < 1.5W |
| Power Supply: | Normal |
| Power SupplyV: | DC12V / 80mA (approximate) |
| Resolution: | PAL:976x582 / NTSC:976x494 |
| Sensor: | CCD |
| Sensor Brand: | Sony |
| Special Features: | No |
| Storage: | None |
| Style: | Mini Camera |
| Supported Operating Systems: | No |
| Technology: | No |
| TF Card: | None |
| TV lines: | 650TVL |
| Type: | Analog Camera |
| Video Output: | CVBS, 1.0Vp-p, 75 ohm |
