300M USB VGA KVM Extender over Cat 5/5e/6 UTP Cable

Features
Extends your KVM console (VGA monitor, USB keyboard, mouse) connection distances up to 300m over UTP cable.
Superior video quality: up to 1920 x 1200.
Dual console operation: control your system from both the local and remote USB keyboard, monitor, and mouse consoles.
Incorporating a compensation adjustment function at the remote unit for greater video quality.
Using single cable (cat 5/5e/6), instead of bulky, expensive, standard cables, to provide a neater, more convenient, more reliable data transfer connection.
Supports (USB and PS/2 port) keyboard and mouse, it supports (VGA) port monitor.
Supports real time DDC communication.
Supports DOS, Windows, Linux, Unix system.
Anti-lightning and anti-invasion protection: withstand air-discharge 15KV, contiguity-discharge 8KV.
Wall mountable.
Widely apply in the computer, monitor, security, multimedia teaching systems and so on.
Specifications
Interface VGA Video and USB Signal
Application extend VGA video and USB signal over single Cat 5/5e/6 cable up to 300m
Input connector 1-ch VGA, 1-ch USB
Output connector 1-ch VGA, 2-ch USB
Local output HD 15pin VGA
Bandwidth 500MHz
Input level range 0.5-2.0 volts P-P
Input level error less than 3mV
Input/output impedance 75 ohm
Echo Ullage -30db @ 5MHz
Max. DC compensation ±5Mv-0
SNR 60dB
Connector Standard HDB15, USB, Mini-DIN6, RJ45
Video standard VGA, SVGA, XGA, SVGA, UXGA, LCD
Cable standard CAT5, CAT5e, CAT6 UTP
KVM Extender Sender Size 9.5L x 7.5W x 2.5H cm
KVM Extender Receiver Size 9.5L x 7.5W x 2.5H cm
Weight 740g
Package included 1 x VGA KVM Extender(transmitter and receiver), 2 x Power Adapter, 1 x User Manual
Certification CE, FCC, RoHS
