24V Adjustable Pulse Trigger Delay Cycle Timer Delay Switch Relay Control Module

24V Adjustable Pulse Trigger Delay Cycle Timer Delay Switch Relay Control Module
Eachine1
sku: 1239977
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$6.28
Shipping from: China
   Description
Special attention: the relay output is passive contact, uncharged output, control a line on and off. Feature: Delay time range: 0.1 seconds minimum, up to 999 minutes adjustable. Output capacity: can control within 30v5A DC or within 220v5A AC equipment Quiescent current: 20mA Working current: 50mA Life: >100,000 times Working temperature: -40C to 85C Size: 64.2mm * 34.8mm * 18.5mm Function: P-1: The signal triggers the relay to pull in, when the time is up, the relay is off, during the delay A: Re-trigger invalid B: Re-trigger timing again C: Re-trigger relay reset finish timing P-2: Signal triggering starts counting time T1, when time reaches the relay pull-in, time T2 is off (reset) A: Re-trigger invalid B: Trigger again re-count C: Do not need to trigger the power to start the delay P-3: Recycling use: Turn on T1, Disconnect T2, Endless cycle. T1 and T2, the time is adjustable If you connect or disconnect a parameter to 0, can achieve power-on delay or power delay, power off does not cycle A: After power on, the relay immediately energized B: After the relay is energized, the relay is turned off and then ON again P-4: Have signal, the relay is pull in and keep, when the signal is disappears, the timer starts. When the time is up, the relay is off. During the delay time, the signal is again given, the delay is canceled, the relay is kept, the signal disappears and the time is re-counted. Key Settings Description: K1: Function selection key: long press K1 key for 2 seconds, appear P * short press K1 to select mode, press K2 to enter mode K2: Shift key: Press to adjust the flashing position of digital tube, which digital tube flashes, K3 will adjust the value of flashing digital tube. Until you press K2, digital tube no longer flashing, time setting is complete, automatically save the set time and power-off memory K3: Digital tube flashing: K3 adjust the digital changes, 0 to 9 followed by changes. When the digital tube display is normal: K3 adjust the decimal point position, the decimal point in the first digit means from 0 to 999 minutes; in the tens digit means 0 to 99.9 seconds; no decimal point means 0 to 999 seconds Note 1: After selecting the working mode, short press K1 to enter the function of A, B, C switching, the digital tube will not display A or B or C, only after short press K1 to trigger signal then it will default display A Note 2: Function P-2 and P-3 have two groups of time to be adjusted, prees K2 six times for one group, the first three times to adjust one time, and another three times for the second time. (Blue LED light indicates the pull in of relay time and blue LED light indicates the disconnect time of setting relay.) Package includes: 1 x Relay module
