20 String 60V 90A Iron Lithium Battery Protection Board With Balance For Electric Tricycle Motorcycle

Feature: Model: 20 series 60V 90A battery protection board Size: 120 x 60 x 16mm Continuous operating current: 90A Charging current: 90A Balanced charge: Yes Short circuit protection: Yes Suitable for assembly: Nominal 3.2V batteries / 20 strings Details Specification Unit Discharging Continuous discharge current 90A Instantaneous discharge current 160A Charging Charging voltage 75V Charging current 90(MAX.)A Over charge protection Overcharge detection voltage 3.750.025V Overcharge protection delay 1000mS Overcharge release voltage 3.60.08V Battery balance Battery balance detection voltage 3.60.025V Battery balance release voltage 3.60.05V Battery balance current 505mA Over discharge protection Over-discharge detection voltage 2.100.05V Over discharge detection delay 100mS Over discharge release voltage 2.30.1V Over current protection Overcurrent detection voltage 150mV Overcurrent detection delay 15mS Overcurrent protection current 20020A Overcurrent protection release condition Disconnect the load Short circuit protection Short circuit protection condition External load short circuit Short circuit detection delay 200uS Short circuit protection release condition Disconnect negative open Temperature protection Temperature protection / Internal resistance Main circuit conduction internal resistance 15m Self-consumption Working current 70uA Sleep current (when battery is over-discharged) 10uA Operating temperature Temperature range -30 to +80C Package includes: 1 x Battery Protection Board 1 x Cable
