2.4GHz CC2538 ARM Cortex-M3 Controller Development Board 6LoWPAN for Contiki System Wireless Transceiver Module 5V DC

nullDescription The CC2538SF53 is an ideal system on a chip SoC for high performance Zibee applications The device includes a powerful MCU system based on the ARM Cortex M3 with up to 32KB of on chip rAM and up to 512KB of on chip flash memory and reliable IEEE802 15 4 RF functionality Compared with other SOCs such as CC2530 only 8KRAM CC2538 can run the most promising 6LoWpaN COAP MQTT and other protocols Features ARM Cortex M3 Controller 32MHz Running clock512KB programmable memory space Support OTA Support ZiBee application configuration 32KB RAM Support cJTAG and JTAG debugging 2 4GHz IEEE 802 15 4 97dBm RF Receiving sensitivity 7dBm programmable output powerSpecifications Model SM14Z2538Work Voltage DC 5VControl IC CC2538SF53Timer 412Bit ADC 8SPI 2UART 2IIC 1GPIO 32Work Temperature 25℃ 85℃Work Humidity 5 95 RHSize 80 x 60 x 15mmPackage Included 1 x 2 4GHz CC2538 ARM Cortex M3 Controller Development Board
