1Pc 433MHz 220V 10A 1CH Channel Wireless Relay Remote Control Switch Receiver

Specification: 1. Input Voltage: AC85V-AC220V 2. RF Frequency: 433MHZ 3. RF Working mode:Super heterodyne receiver 4. Receiver Sensitivity: -107dBm 5. Remote Control Distance: >100 meter(In open environment) 6. Decoding Way: MCU Software decoding 7. Can store the number of remote control:32 8. Support remote control type: Fixed code, learning code 9. Channel: 1CH 10 .Multiple working modes: (Jog/Non-Latched ,inter-lock/Latched ,self-lock /Self-Latched) 11. Wiring Method:Fixed wiring terminal 12. Rated load:10A 250VAC / 10A 125VAC, 10A 30VDC / 10A 28VDC 13. Dimension:5.4cm*3.1cm*1.4cm Working/output method: 1. Jog/Non-Latched: Press one button is Working /ON. Loosen your finger on the same button is Stop/OFF. One channel switch need one buttons remote control. 2. Self -lock/Self-Latched: Press one button for one time is working/ON. Press the same button again is stop/OFF. One channel switch need one buttons remote control. 3. Inter-lock /Latched: Press one button is working/ON, press another button is stop/OFF. One channel switch need 2 buttons remote control. Clear & Learn Code: 1. Clear function - After pressing the "KEY" button 8 times, the LED will go off and release all the remote control data in the memory. When the LED flashes for 5 times, it indicates that the clear function is completed. 2. learning function - click the learning button "KEY" LED indicator light indicates that the microprocessor to enter the learning state of the code, press the matching wireless remote control button, LED light blinks 3 times then turn off means Code success. 3. LED flashes to determine the selected function. * Flashing 1 time - Jogging function * Flashing 2 times - Self-locking function * Blink 3 times - Interlock function Note: When using for the first time, make sure to clear the factory code and clear the remote control code. Package included: 1 x 220V 1 Channel Wireless Relay Switch
