1Hz-65534Hz DDS Function Signal Generator Module Sawtooth Triangle Wave, 501 Original

1Hz-65534Hz DDS Function Signal Generator Module Sine Sawtooth Triangle Wave Kit Descriptions:Function (waveform) signal generator can produce some specific periodic time function waveform (sine, square, triangle, sawtooth, etc.) signal, the frequency range is 1Hz-65534Hz.Features:Small size, powered by DC 7V-9V, easy and portable for use.DDS frequency range: 1Hz-65534Hz, high-speed frequency (HS) output up to 8MHz.DDS signal amplitude of the offset amount can be adjusted separately by two potentiometers.DDS signals: sine wave, square wave, sawtooth, reverse sawtooth, triangle wave, the ECG wave and noise wave.LCD display for clear reading, intuitive 5 buttons for convenient operation.The power automatically restore the last used configuration.Key Functions:UP output waveform select.DOWN output waveform select.LEFT output frequency -.RIGHT output frequency +.STOP / START the output stop / start.\"UP\" key waveforms order:ECG = electrocardiogram wave (in the OFF state, the \"left\" and \"right\" keys to set the output frequency. Middle button start, all of the following waveform set).Rev Sawtooth = reverse sawtooth.SawTooth = sawtooth.Triangle = triangle wave.Square = square wave.Specifications:Display: 1602 LCDOperating Voltage: DC 7V-9VDDS Frequency Range: 1Hz-65534HzFrequency(HS) Output: up to 8MHzSection into the Value: 1, 10 , 100, 1000, 10000 HzOffset: 0.5pp-5VppAmplitude Amount: 0.5Vpp-14VppPCB Board Size: approx. 100 * 80mm / 3.94 * 3.15inProduct Weight: approx. 100g / 3.53ozNote: Please allow 1-3 cm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.1 x DDS Function Signal Generator
