1Hz-500KHz DDS Functional Signal Generator Frequency Generator Sine + Square + Triangle + Sawtooth Waveform Meter

Instruction This functional signal generator can test many kinds of waveforms such as sine square triangle positive and negative sawtooth waveform It is specially designed for those professional workers Features It is small but has many functions easy to operate and carry It can be used with the oscilloscope to test and debug electronic circuits the frequency response of audio amplifier and impulse response The square waveform is suitable for the oscilloscope attenuator and the adjustment of the probe impulse response It also can calibrate the sweep time factor of the oscilloscope Have a filter can be opened and closed to suit the output of the sine wave and pulse wave Specifications The Output Signal Types sine square triangle positive and negative sawtooth waveform Frequency Range sine wave is 1Hz 500kHz other kinds of waveforms is 1Hz 20kHz Resolution 1HzSine Wave Distortion under 1kHz1 over 1kHz 0 5 DC Offset Range 10V Can be closed Output Range 10V P P Output Impedance 50ohmPower Supply Voltage DC3 5 10V Display LCD Item Size 14 x 8 x 3 5cm 5 51 x 3 15 x 1 38inLCD Screen 6 5 x 1 5cm 2 56 x 0 59inItem Weight 197 5g 6 96ozPackage Size 23 x 16 x 3 5cm 9 06 x 6 3 x 1 38inPackage Weight 202 5g 7 15oz Package includes 1 x Signal Generator1 x USB to DC Power Cable
