1D 2D QR Code Scanning Embedded Module One-dimensional Two-dimensional Scanning Head Barcode Scanner Reading Engine

Scope of application: Self-service terminal Channel gate Locker Handheld Terminal Game machine Barcode scanning QR code payment Compatible system: Linux, Android, Windows XP, Windows 7, Windows 8, Windows10, MAC Technical Parameters Size 21.4 x 14.3 x 11mm Image Sensor CMOS Resolution 640 (horizontal) x 480 (vertical) Lighting white LED Reading accuracy >=5mil Focus LED650+-10nm Symbol contrast >=30% Reading code system 2D PDF417, QRcode, Datamatrix, Chinese Sensible Code 1D UPC/EAN, Code128, Code93, Code39, Code11, Codebar, MSI Pressey, ISBN, Standard 2 of 5, interleaved 2 of 5, Industrial 2 of 5 Typical reading depth of field EAN-13 (13mil) 60-200mm Code-39 (6.67mil) 80-115mm Data Matrix (10mil) 30-95mm QR Code (20mil) 50-200mm PDF 417 (13.34mil) 30-220mm Bar code sensitivity Tilt +-45 C Deflection +-50 C Rotate 360C Field of view Level 53 Vertical 40 Recognition speed 30 frames / sec Operating Voltage +3.3V Operating current 160mA (typical) 190mA (max) Standby current 58mA Sleep current
