16S 48V 20A PCB PCM LFP Battery BMS Motorcycle Protection Board + Cabel

Specification: Name: 16S 48V 20A LFP Battery Protection Board Continuous Discharging Current: 20A Instantaneous Diacharge Current: 100A Charging Voltage: 60V Charging Current: 20A(Max.) Over-charge Detect: 3.750.025V Protect Delay: 1000ms Over-charge Release: 3.60.05V Over-discharge: 2.10.08V Over-discharge Detect Delay: 100mS Release Voltage: 2.30.1V Detect Voltage: 200mV Detect Delay: 15mS Current Detect: 15010A Resistance: 15m Working Current: 60uA Sleep Current(when Over-discharge): 10uA Working Temperature: -30~80 Size: 69mm*51.5mm*10mm Balance Detection Voltage: 3.60.025V Balance Release Voltage: 3.60.05V Balance Current: 485 mA Short Circuit Detection Delay: 200uS Main Function: Over charge protection, over discharge protection function, short circuit protection function, over current protection function,no with band balance. Connections: Step1:Connect charging /discharging wire battery pack negative wire Step2: After confirm the wires are connected OK, plug the connector cable in the BMS DO NOT plug CONNECTOR CABLE in the BMS before connect wire.. Package Included: 1 X 16S 48V 20A Li-ion Battery Protection Board 1 X Cabel Wire
