16 Series 60V 45A Lithium Battery Protection Board For Electric Tricycle Motorcycle Power Protection With Balance

Feature: Model: 16 series 60V 45A battery protection board Size: 120 x 60 x 9mm Continuous operating current: 45A Charging current: 45A Balanced charge: Yes Short circuit protection: Yes Suitable for assembly: Nominal 3.7V batteries / 16 strings Details Specification Unit Discharging Continuous discharge current 45A Instantaneous discharge current 100A Charging Charging voltage 67.2V Charging current 45(MAX.)A Over charge protection Overcharge detection voltage 4.280.05V Overcharge protection delay 100mS Overcharge release voltage 4.080.05V Battery balance Battery balance detection voltage 4.20.025V Battery balance release voltage 4.20.05V Battery balance current 455mA Over discharge protection Over-discharge detection voltage 2.550.08V Over discharge detection delay 50mS Over discharge release voltage 2.90.1V Over current protection Overcurrent detection voltage 150mV Overcurrent detection delay 15mS Overcurrent protection current 13010A Overcurrent protection release condition Disconnect the load Short circuit protection Short circuit protection condition External load short circuit Short circuit detection delay 200uS Short circuit protection release condition Disconnect negative open Temperature protection Temperature protection / Internal resistance Main circuit conduction internal resistance 15m Self-consumption Working current 50uA Sleep current (when battery is over-discharged) 10uA Operating temperature Temperature range -30 to +80C Package includes: 1 x Battery Protection Board 1 x Cable
