13pcs ER11 1-7mm Spring Collet Set Collet Kit for CNC Engraving Machine & Grinding Tool

Correct clamp mounting methods: 1. Put the chuck into the presser cap gently rotate the collet spring when the eccentric part of the collet spring groove recessed in the presser cap. In the direction of the arrow and using the same force to push the clamp spring you can mount the pressure cap. 2. Place the collet spring and cap together on the chuck or spindle body. Insert into the clamping hole after wiping the cylindrical rod use a wrench to tighten the pressure cap until the tool is tight before use. Note: Avoid securing the presser cap with an uninstalled tool to prevent damage to the clamp spring. 3. Using a wrench loosen the pressure cap and remove the chuck or tool then remove the tool. In the direction of the arrow push back the spring of the clamp then if necessary replace the other spring of the clamp. Specifications: Model: ER11 Material: First Class 1065 Carbon Steel Clamping range: 1mm to 7mm (1mm 1.5mm 2mm 2.5mm 3mm 3.5mm 4mm 4.5mm 5mm 5.5mm 6mm 6.5mm 7mm) End of Stroke Tolerance: Total Height: 18mm / 0.71inch Outer diameter (max.): 11.5 mm / 0.5 inch For metric shank sizes: For example 1mm collet fits metric shank 2mm collet fits 2mm metric shank The package includes: 1set(13pcs) x ER11 Collet
